Receiver Type 78

This unit is a front-end converter covering the frequency range of 2.4Mc/s to 13.0Mc/s which and produced an IF output of 560kc/s.
The IF amplifier, detector and audio amplifier stages were located in the Modulator Type 76 that was also part of ARI 5206.

Sec/Ref: 10D/1307
